500m masofa 850nm lite infraqizil laser modul

Model

Sg - IR850 - 5L

Samarali masofa

≥500m

Rejimi

Falsel

To'lqin uzunligi

850 ± 10nm

Lazer xavfsizlik tasnifi

3b sinf

Kirish quvvat

<10.0w

Lazerli chip kuchi

2.2 ± 0.3w

Chiqish engil quvvat

2.0 ± 0.3w

Lazer nuri burchak

Uzunlik 1,8 °, samarali masofa> 500m, nur sporti

71 ° burchakli, samarali masofa> 40M

Kattalashtirish tezligi

≤ 3s (uzoq burchak yaqin)

Boshqarish rejimi

UART_TTL, Rs - 485, qo'llanma

Aloqa interfeysi

Rs - 485, ttl232, qo'lda boshqarish

Aloqa protokoli

PELCO - D (9600bPS standart, 115200b / s.a.) ixtiyoriy uchun 2400b / s

Ish rejimi

Davom ettirmoqda

Xizmat hayoti

≥ 50000h

Kirish quvvat

DC12V ± 10%

Operatsiya oqimi

<0.9a

Operatsion harorat

- 40 ° C ~ + 70 ° C

Saqlash harorati

- 40 ° C ~ + 80 ° C

O'lchov

61,7mm * 30 mm * 41.2MM

Vazn

Taxminan. 85g
